• Max. Part Width: 2.125” (54 mm)
• Max. Part Length: 15” (380 mm)
• Max. Tonnage: 20 (18.1 metric tons)
• Max. Material Thickness
> Stainless: .040” (1 mm)
> CRS: mild steel .050” (1.25 mm)
> BECU, Brass, CU, Alum: .062” (1.6 mm)
> Other materials on a part by part basis
• Min. Material Thickness: .004" (0.100 mm)
|
• Max. Wire Diameter: .188” (4.8 mm)
• Min. Wire Diameter: .005” (0.125 mm)
• Tolerances
> Form to feature: +/-.005“ (0.125 mm)
> Form to form: +/-.005“ (0.125 mm)
> Feature size: +/-.001“ (0.025 mm)
> Notch to form: +/-.005” (0.125 mm)
> Bend Angle: +/- 2 deg (preferred)
> Feed Accuracy .0002" (0.005 mm)
|
